Technical Specifications of KPSE07E14-19SDX
| Datasheet |  KPSE07E14-19SDX datasheet |
|---|
| Standard Package | 1 |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Circular Connectors |
|---|
| Series | MIL-DTL-26482 Series I, KPSE |
|---|
| Packaging | Bulk |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 19 |
|---|
| Shell Size - Insert | 14-19 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Bulkhead - Front Side Nut |
|---|
| Termination | Crimp |
|---|
| Fastening Type | Bayonet Lock |
|---|
| Orientation | N (Normal) |
|---|
| Ingress Protection | Environment Resistant |
|---|
| Shell Material, Finish | Aluminum Alloy, Olive Drab Cadmium Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | Backshell |
|---|
| Contact Finish Thickness | 50μin (1.27μm) |
|---|
| Current Rating | 7.5A |
|---|
| Voltage - Rated | 600VAC, 850VDC |
|---|
| Operating Temperature | -55°C ~ 125°C |
|---|
| Mating Products | IKPSE06F14-19P-ND - CONN PLUG 19POS CBL MNT W/PINS IKPSE06E14-19P-ND - CONN PLUG 19POS CBL MNT W/PINS IKPSE6F14-19PDX-ND - CONN PLUG 19POS W/PIN IKPSE06F14-19PDX-ND - CONN PLUG 19POS W/PIN INLINE KPSE06P14-19P-ND - CONN PLUG 19POS INLINE PIN IKPSE6E14-19PF185-ND - CONN PLUG 19POS CBL MNT W/PINS IKPSE6E14-19PDN-ND - CONN PLUG 19POS CBL MNT W/PINS IKPSE06E14-19PDN-ND - CONN PLUG 19POS CBL MNT W/PINS IKPSE06F14-19PDN-ND - CONN PLUG 19POS INLINE W/PIN IKPSE08E14-19P-ND - CONN PLUG 19POS CBL MNT W/PINS IKPSE08F14-19P-ND - CONN PLUG 19POS CBL MNT W/PINS IKPT06E14-19PDN-ND - CONN PLUG 19POS W/PIN INLINE IKPT06E14-19P-ND - CONN PLUG 19POS INLINE W/PIN IKPTR6E14-19P-ND - CONN PLUG 19POS W/PIN INLINE IKPT08E14-19P-ND - CONN PLUG 19POS W/PIN INLINE R/A IKPT08F14-19P-ND - CONN PLUG 19POS W/PIN INLINE R/A IKPT06J14-19P-ND - CONN PLUG 19POS INLINE W/PIN IKPSE06J14-19P-ND - CONN PLUG 19POS CBL MNT W/PINS KPSE08P14-19P-ND - CONN PLUG 19POS INLINE RA PIN KPT06P14-19P-ND - CONN PLUG 19POS INLINE PIN KPT08P14-19P-ND - CONN PLUG 19POS INLINE RA PIN KPT6E14-19PDN-ND - CONN PLUG 19POS INLINE PIN |
|---|
| Other Names | KPSE07E1419SDX |
|---|
We can supply ITT Cannon, LLC part# KPSE07E14-19SDX. Use the request quote form to request KPSE07E14-19SDX pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number KPSE07E14-19SDX. The price and lead time for KPSE07E14-19SDX depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# KPSE07E14-19SDX. We look forward to doing business with you.
