HFW14R-1STAE1HLF
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HFW14R-1STAE1HLF |
|---|---|
| Manufacturer | Amphenol FCI |
| Description | 14 Position FPC Connector Contacts, Bottom 0.039" (1.00mm) Surface Mount, Right Angle |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| HFW14R-1STAE1HLF Price |  |
Technical Specifications of HFW14R-1STAE1HLF
| Category | Connectors, Interconnects |
|---|---|
| Family | FFC, FPC (Flat Flexible) Connectors |
| Manufacturer | Amphenol-FCI |
| Series | HFW-R |
| Packaging | Tape & Reel (TR) |
| Flat Flex Type | FPC |
| Mounting Type | Surface Mount, Right Angle |
| Connector/Contact Type | Contacts, Bottom |
| Number of Positions | 14 |
| Pitch | 0.039" (1.00mm) |
| Termination | Solder |
| FFC, FCB Thickness | 0.30mm |
| Height Above Board | 0.075" (1.90mm) |
| Locking Feature | - |
| Cable End Type | Tapered |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Housing Material | Polyamide (PA6T), Nylon 6T, Glass Filled, Halogen Free |
| Actuator Material | - |
| Features | - |
| Voltage Rating | 100V |
| Operating Temperature | -55°C ~ 105°C |
| Material Flammability Rating | UL94 V-0 |
| Current Rating | 1A |
