JXD1-0006NL
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | JXD1-0006NL |
|---|---|
| Manufacturer | Pulse Electronics Corporation |
| Description | 1 Port RJ45 Magjack Connector Through Hole 10/100 Base-TX, AutoMDIX |
| Lead Free Status / RoHS Status | Not applicable / RoHS Compliant |
| JXD1-0006NL Price |  |
Technical Specifications of JXD1-0006NL
| Category | Connectors, Interconnects |
|---|---|
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Pulse-Electronics-Corporation |
| Series | - |
| Packaging | Tray |
| Connector Type | RJ45 |
| Number of Ports | 1 |
| Number of Rows | 1 |
| Applications | 10/100 Base-TX, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.543" (13.80mm) |
| LED Color | Does Not Contain LED |
| Number of Cores per Jack | 4 |
| Shielding | Shielded, EMI Finger |
| Features | Board Lock |
| Tab Direction | Up |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Shield Material | Brass |
| Housing Material | Polyamide (PA66), Nylon 6/6 |
| Operating Temperature | -40°C ~ 85°C |
