7498011008
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 7498011008 |
|---|---|
| Manufacturer | Wurth Electronics Inc |
| Description | 1 Port RJ45 Magjack Connector Surface Mount 10/100 Base-T, AutoMDIX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 7498011008 Price |  |
Technical Specifications of 7498011008
| Datasheet |  7498011008 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Wurth-Electronics-Inc |
| Series | WE-RJ45 |
| Packaging | Tray |
| Connector Type | RJ45 |
| Number of Ports | 1 |
| Number of Rows | 1 |
| Applications | 10/100 Base-T, AutoMDIX |
| Mounting Type | Surface Mount |
| Orientation | 90° Angle (Right) |
| Termination | Solder |
| Height Above Board | 0.535" (13.59mm) |
| LED Color | Does Not Contain LED |
| Number of Cores per Jack | 4 |
| Shielding | Shielded, EMI Finger |
| Features | Board Guide, Solder Retention |
| Tab Direction | Down |
| Contact Material | Tin |
| Contact Finish | Gold |
| Contact Finish Thickness | 30μin (0.76μm) |
| Shield Material | Copper Alloy |
| Housing Material | Thermoplastic |
| Operating Temperature | -40°C ~ 85°C |
