V811-1X4T-06-F
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | V811-1X4T-06-F |
|---|---|
| Manufacturer | Bel Fuse Inc. |
| Description | 4 Port RJ45 Magjack Connector Through Hole 10/100 Base-T, AutoMDIX |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| V811-1X4T-06-F Price |  |
Technical Specifications of V811-1X4T-06-F
| Datasheet |  V811-1X4T-06-F datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Modular Connectors - Jacks With Magnetics |
| Manufacturer | Bel-Fuse-Inc. |
| Series | MagJack? |
| Packaging | Tray |
| Connector Type | RJ45 |
| Number of Ports | 4 |
| Number of Rows | 1 |
| Applications | 10/100 Base-T, AutoMDIX |
| Mounting Type | Through Hole |
| Orientation | Vertical |
| Termination | Solder |
| Height Above Board | 1.015" (25.78mm) |
| LED Color | Does Not Contain LED |
| Number of Cores per Jack | 4 |
| Shielding | Shielded, EMI Finger |
| Features | Board Lock |
| Tab Direction | User Selectable |
| Contact Material | Copper Alloy |
| Contact Finish | Gold |
| Contact Finish Thickness | 50μin (1.27μm) |
| Shield Material | Copper Alloy |
| Housing Material | Polybutylene Terephthalate (PBT) |
| Operating Temperature | 0°C ~ 70°C |
