ZW-07-11-L-S-550-120
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | ZW-07-11-L-S-550-120 |
|---|---|
| Manufacturer | Samtec Inc. |
| Description | CONN BOARD STKR HDR 7POS 2.54MM |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| ZW-07-11-L-S-550-120 Price |  |
Technical Specifications of ZW-07-11-L-S-550-120
| Datasheet |  ZW-07-11-L-S-550-120 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Board Spacers, Stackers |
| Manufacturer | Samtec-Inc. |
| Series | Flex Stack, ZW |
| Packaging | Tube |
| Number of Positions | 7 |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Length - Overall | 0.930" (23.62mm) |
| Length - Post (Mating) | 0.260" (6.60mm) |
| Length - Stack Height | 0.551" (14.00mm) |
| Length - Tail | 0.120" (3.05mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Finish - Post (Mating) | Gold |
| Contact Finish Thickness - Post (Mating) | 10μin (0.25μm) |
| Color | Black |
