0877972000
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 0877972000 |
|---|---|
| Manufacturer | Molex, LLC |
| Description | 2.54MM C-GRID DRDW T/H HDR 20CKT |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 0877972000 Price |  |
Technical Specifications of 0877972000
| Datasheet |  0877972000 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Board Spacers, Stackers |
| Manufacturer | Molex,-LLC |
| Series | C-Grid? 87797 |
| Packaging | Tray |
| Number of Positions | 20 |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Length - Overall | 1.220" (31.00mm) |
| Length - Post (Mating) | 0.334" (8.49mm) |
| Length - Stack Height | 0.551" (14.00mm) |
| Length - Tail | 0.334" (8.49mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Finish - Post (Mating) | Gold |
| Contact Finish Thickness - Post (Mating) | 30μin (0.76μm) |
| Color | Black |
