HW-05-09-L-D-400-SM
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | HW-05-09-L-D-400-SM |
|---|---|
| Manufacturer | Samtec Inc. |
| Description | CONN HEADER .25" VERT 10POS SMD |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| HW-05-09-L-D-400-SM Price |  |
Technical Specifications of HW-05-09-L-D-400-SM
| Datasheet |  HW-05-09-L-D-400-SM datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Board Spacers, Stackers |
| Manufacturer | Samtec-Inc. |
| Series | Flex Stack, HW |
| Packaging | Tube |
| Number of Positions | 10 |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Length - Overall | 0.665" (16.89mm) |
| Length - Post (Mating) | 0.265" (6.73mm) |
| Length - Stack Height | 0.400" (10.16mm) |
| Length - Tail | - |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Contact Finish - Post (Mating) | Gold |
| Contact Finish Thickness - Post (Mating) | 10μin (0.25μm) |
| Color | Black, Natural |
