Include WithHome > Products > Connectors, Interconnects > Rectangular - Board to Board Connectors - Headers, Male Pins > 1-1470109-0
1-1470109-0
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1-1470109-0 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | CONN HEADR .079" 10POS VERT TIN |
| Lead Free Status / RoHS Status | Contains lead / RoHS Compliant |
| 1-1470109-0 Price |  |
Technical Specifications of 1-1470109-0
| Datasheet |  1-1470109-0 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Headers, Male Pins |
| Manufacturer | TE-Connectivity-AMP-Connectors |
| Series | AMPMODU |
| Packaging | Bulk |
| Connector Type | Shrouded |
| Number of Positions | 10 |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 2 |
| Row Spacing | 0.079" (2.00mm) |
| Height Stacking (Mating) | - |
| Molding Height Above Board | 0.256" (6.50mm) |
| Contact Mating Length | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Contact Finish | Tin |
| Contact Finish Thickness | 100μin (2.54μm) |
| Features | - |
| Color | Natural |
