7-174820-7
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 7-174820-7 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | CONN HEADER .049" 17POS SMT TIN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 7-174820-7 Price |  |
Technical Specifications of 7-174820-7
| Datasheet |  7-174820-7 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular - Board to Board Connectors - Headers, Male Pins |
| Manufacturer | TE-Connectivity-AMP-Connectors |
| Series | FP |
| Packaging | Bulk |
| Connector Type | Shrouded |
| Number of Positions | 17 |
| Number of Positions Loaded | All |
| Pitch | 0.049" (1.25mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Height Stacking (Mating) | - |
| Molding Height Above Board | 0.234" (5.95mm) |
| Contact Mating Length | - |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Features | Board Guide |
| Color | Black |
