BM15B-PASS-1-TFT(LF)(SN)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | BM15B-PASS-1-TFT(LF)(SN) |
|---|---|
| Manufacturer | JST Sales America Inc. |
| Description | 15 Positions Header, Shrouded Connector 0.079" (2.00mm) Surface Mount Tin |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| BM15B-PASS-1-TFT(LF)(SN) Price |  |
Technical Specifications of BM15B-PASS-1-TFT(LF)(SN)
| Datasheet |  BM15B-PASS-1-TFT(LF)(SN) datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | JST-Sales-America-Inc. |
| Series | PA |
| Packaging | Tape & Reel (TR) |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 15 |
| Number of Positions Loaded | All |
| Pitch | 0.079" (2.00mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | - |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Fastening Type | Locking Ramp |
| Features | Board Guide, Solder Retention |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Color | Natural |
