S4B-XH-SM4-TB(LF)(SN)
(SN).JPG)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | S4B-XH-SM4-TB(LF)(SN) |
|---|---|
| Manufacturer | JST Sales America Inc. |
| Description | 4 Positions Header, Shrouded Connector 0.098" (2.50mm) Surface Mount, Right Angle Tin |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| S4B-XH-SM4-TB(LF)(SN) Price |  |
Technical Specifications of S4B-XH-SM4-TB(LF)(SN)
| Datasheet |  S4B-XH-SM4-TB(LF)(SN) datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | JST Sales America Inc. |
| Series | XH |
| Packaging | Cut Tape (CT) |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 4 |
| Number of Positions Loaded | All |
| Pitch | 0.098" (2.50mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Contact Mating Length | - |
| Mounting Type | Surface Mount, Right Angle |
| Termination | Solder |
| Fastening Type | Detent Lock |
| Features | Solder Retention |
| Contact Finish | Tin |
| Contact Finish Thickness | - |
| Color | Natural |
