AWHW26-G-SMD-R
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | AWHW26-G-SMD-R |
|---|---|
| Manufacturer | Assmann WSW Components |
| Description | 26 Positions Header, Shrouded Connector 0.100" (2.54mm) Surface Mount Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| AWHW26-G-SMD-R Price |  |
Technical Specifications of AWHW26-G-SMD-R
| Datasheet |  AWHW26-G-SMD-R datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Male Pins |
| Manufacturer | Assmann WSW Components |
| Series | - |
| Packaging | Tube |
| Contact Type | Male Pin |
| Connector Type | Header, Shrouded |
| Number of Positions | 26 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Contact Mating Length | - |
| Mounting Type | Surface Mount |
| Termination | Solder |
| Fastening Type | - |
| Features | Polarizing Key |
| Contact Finish | Gold |
| Contact Finish Thickness | Flash |
| Color | Black |
