0009485096
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 0009485096 |
|---|---|
| Manufacturer | Molex, LLC |
| Description | 9 Position Receptacle, Bottom Entry Connector 0.156" (3.96mm) Through Hole Gold |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 0009485096 Price |  |
Technical Specifications of 0009485096
| Datasheet |  0009485096 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Receptacles, Female Sockets |
| Manufacturer | Molex, LLC |
| Series | KK? 41815 |
| Packaging | Tray |
| Connector Type | Receptacle, Bottom Entry |
| Contact Type | Female Socket |
| Number of Positions | 9 |
| Number of Positions Loaded | All |
| Pitch | 0.156" (3.96mm) |
| Number of Rows | 1 |
| Row Spacing | - |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | Locking Ramp |
| Features | - |
| Contact Finish | Gold |
| Contact Finish Thickness | 15μin (0.38μm) |
| Color | Natural |
