8520-4500VC
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 8520-4500VC |
|---|---|
| Manufacturer | 3M |
| Description | 20 Position Receptacle Connector 0.100" (2.54mm) Through Hole Gold |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| 8520-4500VC Price |  |
Technical Specifications of 8520-4500VC
| Datasheet |  8520-4500VC datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Rectangular Connectors - Headers, Receptacles, Female Sockets |
| Manufacturer | 3M |
| Series | 8500 |
| Packaging | Bulk |
| Connector Type | Receptacle |
| Contact Type | Female Socket |
| Number of Positions | 20 |
| Number of Positions Loaded | All |
| Pitch | 0.100" (2.54mm) |
| Number of Rows | 2 |
| Row Spacing | 0.100" (2.54mm) |
| Mounting Type | Through Hole |
| Termination | Solder |
| Fastening Type | - |
| Features | Polarizing Key |
| Contact Finish | Gold |
| Contact Finish Thickness | 12μin (0.30μm) |
| Color | Gray |
