214-3339-09-0602J
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 214-3339-09-0602J |
|---|---|
| Manufacturer | 3M |
| Description | IC Socket Adapter DIP, 0.3" (7.62mm) Row Spacing To DIP, 0.3" (7.62mm) Row Spacing Through Hole |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 214-3339-09-0602J Price |  |
Technical Specifications of 214-3339-09-0602J
| Datasheet |  214-3339-09-0602J datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Sockets for ICs, Transistors - Adapters |
| Manufacturer | 3M |
| Series | Textool? |
| Convert From (Adapter End) | DIP, 0.3" (7.62mm) Row Spacing |
| Convert To (Adapter End) | DIP, 0.3" (7.62mm) Row Spacing |
| Number of Pins | 14 |
| Pitch - Mating | 0.100" (2.54mm) |
| Contact Finish - Mating | Gold |
| Mounting Type | Through Hole |
| Termination | Solder |
| Pitch - Post | 0.100" (2.54mm) |
| Contact Finish - Post | Gold |
| Housing Material | Polysulfone (PSU), Glass Filled |
| Board Material | - |
| Termination Post Length | 0.130" (3.30mm) |
| Material Flammability Rating | UL94 V-0 |
| Features | - |
| Current Rating | 1A |
| Operating Temperature | -55°C ~ 125°C |
| Contact Material - Mating | Beryllium Copper |
| Contact Material - Post | Beryllium Copper |
| Contact Finish Thickness - Mating | 30μin (0.76μm) |
| Contact Finish Thickness - Post | 30μin (0.76μm) |
