1986716-4
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 1986716-4 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | 4 Position Terminal Block Plug for Unshrouded Header 0.138" (3.50mm) 90° Free Hanging (In-Line) |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 1986716-4 Price |  |
Technical Specifications of 1986716-4
| Datasheet |  1986716-4 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminal Blocks - Headers, Plugs and Sockets |
| Manufacturer | TE Connectivity AMP Connectors |
| Series | - |
| Packaging | Bulk |
| Type | Plug for Unshrouded Header |
| Number of Positions | 4 |
| Positions Per Level | 4 |
| Number of Levels | 1 |
| Pitch | 0.138" (3.50mm) |
| Header Orientation | - |
| Plug Wire Entry | 90° |
| Termination Style | Screwless - Leg Spring, Push-In Spring |
| Mounting Type | Free Hanging (In-Line) |
| Current - IEC | - |
| Voltage - IEC | - |
| Current - UL | 2A |
| Voltage - UL | 150V |
| Wire Gauge or Range - AWG | 16-20 AWG |
| Wire Gauge or Range - mm2 | 0.5-1.3mm2 |
| Color | Green |
| Operating Temperature | -40°C ~ 110°C |
| Contact Mating Finish | Tin |
| Features | Push Button Actuated, Side Stacking |
