Technical Specifications of XW4L-05A1-V1
| Datasheet |  XW4L-05A1-V1 datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminal Blocks - Wire to Board |
|---|
| Manufacturer | Omron Electronics Inc-EMC Div |
|---|
| Series | XW4 |
|---|
| Packaging | Bulk |
|---|
| Number of Levels | 1 |
|---|
| Positions Per Level | 5 |
|---|
| Pitch | 0.100" (2.54mm) |
|---|
| Mating Orientation | Vertical with Board |
|---|
| Current | 6A |
|---|
| Voltage | 160V |
|---|
| Wire Gauge | 20-26 AWG |
|---|
| Mounting Type | Surface Mount |
|---|
| Wire Termination | Screwless - Leg Spring, Push-In Spring |
|---|
| Features | Board Guide |
|---|
| Color | Black |
|---|
| Operating Temperature | -45°C ~ 125°C |
|---|
| Housing Material | Liquid Crystal Polymer (LCP) |
|---|
| Contact Material - Plating | Copper Alloy - Tin Plated |
|---|
| Clamp Material - Plating | - |
|---|
| Screw Material - Plating | - |
|---|
| Torque - Screw | - |
|---|
| Screw Thread | - |
|---|
We can supply Omron Electronics Inc-EMC Div part# XW4L-05A1-V1. Use the request quote form to request XW4L-05A1-V1 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number XW4L-05A1-V1. The price and lead time for XW4L-05A1-V1 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# XW4L-05A1-V1. We look forward to doing business with you.
