170048-1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | 170048-1 |
|---|---|
| Manufacturer | TE Connectivity AMP Connectors |
| Description | 0.110" (2.79mm) Quick Connect Female 20-24 AWG Crimp Connector Non-Insulated |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| 170048-1 Price |  |
Technical Specifications of 170048-1
| Datasheet |  170048-1 datasheet |
|---|---|
| Category | Connectors, Interconnects |
| Family | Terminals - Quick Connects, Quick Disconnect Connectors |
| Manufacturer | TE Connectivity AMP Connectors |
| Series | - |
| Packaging | Bulk |
| Terminal Type | Standard |
| Gender | Female |
| Tab Width | 0.110" (2.79mm) |
| Tab Thickness | 0.019" (0.50mm) |
| Tab Length | 0.252" (6.40mm) |
| Length - Overall | 0.681" (17.30mm) |
| Termination | Crimp |
| Wire Gauge | 20-24 AWG |
| Insulation | Non-Insulated |
| Mounting Type | Free Hanging (In-Line) |
| Features | - |
| Color | - |
| Contact Material | Brass |
| Contact Finish | - |
| Insulation Diameter | 0.079" ~ 0.118" (2.00mm ~ 3.00mm) |
