Technical Specifications of LCMDX120-14-X
| Category | Connectors, Interconnects |
|---|
| Family | Terminals - Rectangular Connectors |
|---|
| Manufacturer | Panduit Corp |
|---|
| Series | LCMDX |
|---|
| Packaging | Bulk |
|---|
| Terminal Type | Ring, Tubular |
|---|
| Stud/Tab Size | M14 Stud |
|---|
| Terminal Style | Two Stud Holes |
|---|
| Tab Thickness | 0.169" (4.29mm) |
|---|
| Length - Overall | 4.665" (118.49mm) |
|---|
| Width - Outer Edges | 1.201" (30.51mm) |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp, Barrel |
|---|
| Wire Gauge | 120mm2 |
|---|
| Insulation | Non-Insulated |
|---|
| Features | - |
|---|
| Color | - |
|---|
| Contact Finish | Tin |
|---|
| Contact Material | Copper |
|---|
| Diameter - Barrel ID | 0.650" (16.51mm) |
|---|
| Diameter - Barrel OD | 0.827" (21.01mm) |
|---|
| Diameter - Ring ID | 0.630" (16.00mm) |
|---|
We can supply Panduit Corp part# LCMDX120-14-X. Use the request quote form to request LCMDX120-14-X pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number LCMDX120-14-X. The price and lead time for LCMDX120-14-X depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# LCMDX120-14-X. We look forward to doing business with you.
