Technical Specifications of LCMB185-16-X
| Datasheet |  LCMB185-16-X datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminals - Rectangular Connectors |
|---|
| Manufacturer | Panduit Corp |
|---|
| Series | LCMB |
|---|
| Packaging | Bulk |
|---|
| Terminal Type | Ring, Tubular |
|---|
| Stud/Tab Size | M16 Stud |
|---|
| Terminal Style | Single Stud Hole |
|---|
| Tab Thickness | 0.173" (4.39mm) |
|---|
| Length - Overall | 3.961" (100.61mm) |
|---|
| Width - Outer Edges | 1.319" (33.50mm) |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp, Barrel |
|---|
| Wire Gauge | 185mm2 |
|---|
| Insulation | Non-Insulated |
|---|
| Features | - |
|---|
| Color | - |
|---|
| Contact Finish | Tin |
|---|
| Contact Material | Copper |
|---|
| Diameter - Barrel ID | 0.732" (18.59mm) |
|---|
| Diameter - Barrel OD | 0.906" (23.01mm) |
|---|
| Diameter - Ring ID | 0.709" (18.01mm) |
|---|
We can supply Panduit Corp part# LCMB185-16-X. Use the request quote form to request LCMB185-16-X pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number LCMB185-16-X. The price and lead time for LCMB185-16-X depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# LCMB185-16-X. We look forward to doing business with you.
