Technical Specifications of PV18-8R-E
| Datasheet |  PV18-8R-E datasheet |
|---|
| Category | Connectors, Interconnects |
|---|
| Family | Terminals - Ring Connectors |
|---|
| Manufacturer | Panduit Corp |
|---|
| Series | Pan-Term? |
|---|
| Packaging | Bulk |
|---|
| Terminal Type | Circular |
|---|
| Stud/Tab Size | 8 Stud |
|---|
| Thickness | 0.032" (0.81mm) |
|---|
| Width - Outer Edges | 0.310" (7.87mm) |
|---|
| Length - Overall | 0.910" (23.11mm) |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Termination | Crimp |
|---|
| Wire Gauge | 18-22 AWG |
|---|
| Insulation | Insulated |
|---|
| Features | Brazed Seam, Serrated Termination |
|---|
| Color | Red |
|---|
| Contact Material | Copper |
|---|
| Contact Finish | Tin |
|---|
| Insulation Diameter | 0.150" (3.81mm) |
|---|
| Material - Insulation | Vinyl |
|---|
We can supply Panduit Corp part# PV18-8R-E. Use the request quote form to request PV18-8R-E pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number PV18-8R-E. The price and lead time for PV18-8R-E depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# PV18-8R-E. We look forward to doing business with you.
