Technical Specifications of BAT54WS-TP
| Datasheet |  BAT54WS-TP datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Diodes - Rectifiers - Single |
|---|
| Manufacturer | Micro Commercial Co |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Diode Type | Schottky |
|---|
| Voltage - DC Reverse (Vr) (Max) | 30V |
|---|
| Current - Average Rectified (Io) | 200mA (DC) |
|---|
| Voltage - Forward (Vf) (Max) @ If | 1V @ 100mA |
|---|
| Speed | Small Signal =< 200mA (Io), Any Speed |
|---|
| Reverse Recovery Time (trr) | 5ns |
|---|
| Current - Reverse Leakage @ Vr | 500nA @ 30V |
|---|
| Capacitance @ Vr, F | 10pF @ 1V, 1MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | SC-76, SOD-323 |
|---|
| Supplier Device Package | SOD-323 |
|---|
| Operating Temperature - Junction | 125°C (Max) |
|---|
We can supply Micro Commercial Co part# BAT54WS-TP. Use the request quote form to request BAT54WS-TP pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number BAT54WS-TP. The price and lead time for BAT54WS-TP depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# BAT54WS-TP. We look forward to doing business with you.
