Technical Specifications of UPS120/TR13
| Datasheet |  UPS120/TR13 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Diodes - Rectifiers - Single |
|---|
| Manufacturer | Microsemi Corporation |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Diode Type | Schottky |
|---|
| Voltage - DC Reverse (Vr) (Max) | 20V |
|---|
| Current - Average Rectified (Io) | 1A |
|---|
| Voltage - Forward (Vf) (Max) @ If | 450mV @ 1A |
|---|
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
|---|
| Reverse Recovery Time (trr) | - |
|---|
| Current - Reverse Leakage @ Vr | 400μA @ 20V |
|---|
| Capacitance @ Vr, F | 80pF @ 5V, 1MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | DO-216AA |
|---|
| Supplier Device Package | Powermite |
|---|
| Operating Temperature - Junction | -55°C ~ 125°C |
|---|
We can supply Microsemi Corporation part# UPS120/TR13. Use the request quote form to request UPS120/TR13 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number UPS120/TR13. The price and lead time for UPS120/TR13 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# UPS120/TR13. We look forward to doing business with you.
