Technical Specifications of LLSD101C-7
| Datasheet |  LLSD101C-7 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Diodes - Rectifiers - Single |
|---|
| Manufacturer | Diodes Incorporated |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Diode Type | Schottky |
|---|
| Voltage - DC Reverse (Vr) (Max) | 40V |
|---|
| Current - Average Rectified (Io) | 15mA (DC) |
|---|
| Voltage - Forward (Vf) (Max) @ If | 900mV @ 15mA |
|---|
| Speed | Small Signal =< 200mA (Io), Any Speed |
|---|
| Reverse Recovery Time (trr) | 1ns |
|---|
| Current - Reverse Leakage @ Vr | 200nA @ 30V |
|---|
| Capacitance @ Vr, F | 2.2pF @ 0V, 1MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | DO-213AC, MINI-MELF, SOD-80 |
|---|
| Supplier Device Package | Mini MELF |
|---|
| Operating Temperature - Junction | -55°C ~ 125°C |
|---|
We can supply Diodes Incorporated part# LLSD101C-7. Use the request quote form to request LLSD101C-7 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number LLSD101C-7. The price and lead time for LLSD101C-7 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# LLSD101C-7. We look forward to doing business with you.
