Technical Specifications of NSR01L30NXT5G
| Datasheet |  NSR01L30NXT5G datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Diodes - Rectifiers - Single |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Diode Type | Schottky |
|---|
| Voltage - DC Reverse (Vr) (Max) | 30V |
|---|
| Current - Average Rectified (Io) | 100mA (DC) |
|---|
| Voltage - Forward (Vf) (Max) @ If | 530mV @ 100mA |
|---|
| Speed | Small Signal =< 200mA (Io), Any Speed |
|---|
| Reverse Recovery Time (trr) | - |
|---|
| Current - Reverse Leakage @ Vr | 3μA @ 30V |
|---|
| Capacitance @ Vr, F | 7pF @ 5V, 1MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 2-XFDFN |
|---|
| Supplier Device Package | 2-DSN (0.60x0.30) |
|---|
| Operating Temperature - Junction | 150°C (Max) |
|---|
We can supply ON Semiconductor part# NSR01L30NXT5G. Use the request quote form to request NSR01L30NXT5G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number NSR01L30NXT5G. The price and lead time for NSR01L30NXT5G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# NSR01L30NXT5G. We look forward to doing business with you.
