Technical Specifications of JANTX1N3291
| Datasheet |  JANTX1N3291 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Diodes - Rectifiers - Single |
|---|
| Manufacturer | Microsemi IRE Division |
|---|
| Series | Military, MIL-PRF-19500/246 |
|---|
| Packaging | Bulk |
|---|
| Diode Type | Standard |
|---|
| Voltage - DC Reverse (Vr) (Max) | 400V |
|---|
| Current - Average Rectified (Io) | 100A |
|---|
| Voltage - Forward (Vf) (Max) @ If | 1.55V @ 310A |
|---|
| Speed | Small Signal =< 200mA (Io), Any Speed |
|---|
| Reverse Recovery Time (trr) | - |
|---|
| Current - Reverse Leakage @ Vr | 10mA @ 400V |
|---|
| Capacitance @ Vr, F | - |
|---|
| Mounting Type | Chassis, Stud Mount |
|---|
| Package / Case | DO-205AA, DO-8, Stud |
|---|
| Supplier Device Package | DO-205AA (DO-8) |
|---|
| Operating Temperature - Junction | -65°C ~ 200°C |
|---|
We can supply Microsemi IRE Division part# JANTX1N3291. Use the request quote form to request JANTX1N3291 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number JANTX1N3291. The price and lead time for JANTX1N3291 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# JANTX1N3291. We look forward to doing business with you.
