Technical Specifications of BAT54-G3-18
| Datasheet |  BAT54-G3-18 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Diodes - Rectifiers - Single |
|---|
| Manufacturer | Vishay Semiconductor Diodes Division |
|---|
| Series | Automotive, AEC-Q101 |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Diode Type | Schottky |
|---|
| Voltage - DC Reverse (Vr) (Max) | 30V |
|---|
| Current - Average Rectified (Io) | 200mA (DC) |
|---|
| Voltage - Forward (Vf) (Max) @ If | 800mV @ 100mA |
|---|
| Speed | Small Signal =< 200mA (Io), Any Speed |
|---|
| Reverse Recovery Time (trr) | 5ns |
|---|
| Current - Reverse Leakage @ Vr | 2μA @ 25V |
|---|
| Capacitance @ Vr, F | 10pF @ 1V, 1MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
|---|
| Supplier Device Package | SOT-23 |
|---|
| Operating Temperature - Junction | 125°C (Max) |
|---|
We can supply Vishay Semiconductor Diodes Division part# BAT54-G3-18. Use the request quote form to request BAT54-G3-18 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number BAT54-G3-18. The price and lead time for BAT54-G3-18 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# BAT54-G3-18. We look forward to doing business with you.
