MV2109RLRAG
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MV2109RLRAG |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | DIODE TUNING 30V 33PF TO92-2 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MV2109RLRAG Price |  |
Technical Specifications of MV2109RLRAG
| Category | Discrete Semiconductor Products |
|---|---|
| Family | Diodes - Variable Capacitance (Varicaps, Varactors) |
| Manufacturer | ON Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Capacitance @ Vr, F | 36.3pF @ 4V, 1MHz |
| Capacitance Ratio | 3.2 |
| Capacitance Ratio Condition | C2/C30 |
| Voltage - Peak Reverse (Max) | 30V |
| Diode Type | Single |
| Q @ Vr, F | 200 @ 4V, 50MHz |
| Mounting Type | Through Hole |
| Package / Case | TO-226-2, TO-92-2 (TO-226AC) |
| Supplier Device Package | TO-92 |
