MMBV809LT3G
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MMBV809LT3G |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | DIODE TUNING SS 20V SOT-23 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| MMBV809LT3G Price |  |
Technical Specifications of MMBV809LT3G
| Datasheet |  MMBV809LT3G datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Diodes - Variable Capacitance (Varicaps, Varactors) |
| Manufacturer | ON Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Capacitance @ Vr, F | 6.1pF @ 2V, 1MHz |
| Capacitance Ratio | 2.6 |
| Capacitance Ratio Condition | C2/C8 |
| Voltage - Peak Reverse (Max) | 20V |
| Diode Type | Single |
| Q @ Vr, F | 75 @ 3V, 500MHz |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 (TO-236) |
