MMBV2109LT1
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | MMBV2109LT1 |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | DIODE TUNING SS 30V SOT23 |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| MMBV2109LT1 Price |  |
Technical Specifications of MMBV2109LT1
| Datasheet |  MMBV2109LT1 datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Diodes - Variable Capacitance (Varicaps, Varactors) |
| Manufacturer | ON Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Capacitance @ Vr, F | 36.3pF @ 4V, 1MHz |
| Capacitance Ratio | 3.2 |
| Capacitance Ratio Condition | C2/C30 |
| Voltage - Peak Reverse (Max) | 30V |
| Diode Type | Single |
| Q @ Vr, F | 200 @ 4V, 50MHz |
| Mounting Type | Surface Mount |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Supplier Device Package | SOT-23-3 (TO-236) |
