Technical Specifications of 2N6504G
| Datasheet |  2N6504G datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Thyristors - SCRs |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Bulk |
|---|
| Voltage - Off State | 50V |
|---|
| Voltage - Gate Trigger (Vgt) (Max) | 1.5V |
|---|
| Current - Gate Trigger (Igt) (Max) | 30mA |
|---|
| Voltage - On State (Vtm) (Max) | 1.8V |
|---|
| Current - On State (It (AV)) (Max) | 16A |
|---|
| Current - On State (It (RMS)) (Max) | 25A |
|---|
| Current - Hold (Ih) (Max) | 40mA |
|---|
| Current - Off State (Max) | 10μA |
|---|
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 250A @ 60Hz |
|---|
| SCR Type | Standard Recovery |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-220-3 |
|---|
| Supplier Device Package | TO-220AB |
|---|
We can supply ON Semiconductor part# 2N6504G. Use the request quote form to request 2N6504G pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 2N6504G. The price and lead time for 2N6504G depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 2N6504G. We look forward to doing business with you.
