Technical Specifications of TF541S-A
| Datasheet |  TF541S-A datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Thyristors - SCRs |
|---|
| Manufacturer | Sanken |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| Voltage - Off State | 400V |
|---|
| Voltage - Gate Trigger (Vgt) (Max) | 1.5V |
|---|
| Current - Gate Trigger (Igt) (Max) | 200μA |
|---|
| Voltage - On State (Vtm) (Max) | 1.4V |
|---|
| Current - On State (It (AV)) (Max) | 5A |
|---|
| Current - On State (It (RMS)) (Max) | 7.8A |
|---|
| Current - Hold (Ih) (Max) | 4mA |
|---|
| Current - Off State (Max) | 2mA |
|---|
| Current - Non Rep. Surge 50, 60Hz (Itsm) | 80A @ 50Hz |
|---|
| SCR Type | Sensitive Gate |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-220-3 Full Pack |
|---|
| Supplier Device Package | TO-220F |
|---|
We can supply Sanken part# TF541S-A. Use the request quote form to request TF541S-A pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number TF541S-A. The price and lead time for TF541S-A depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# TF541S-A. We look forward to doing business with you.
