PQMH13Z
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | PQMH13Z |
|---|---|
| Manufacturer | NXP Semiconductors |
| Description | TRANS NPN/NPN RET 6DFN |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| PQMH13Z Price |  |
Technical Specifications of PQMH13Z
| Datasheet |  PQMH13Z datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Arrays, Pre-Biased |
| Manufacturer | NXP Semiconductors |
| Series | Automotive, AEC-Q101 |
| Packaging | Tape & Reel (TR) |
| Transistor Type | 2 NPN - Pre-Biased (Dual) |
| Current - Collector (Ic) (Max) | 100mA |
| Voltage - Collector Emitter Breakdown (Max) | 50V |
| Resistor - Base (R1) (Ohms) | 4.7k |
| Resistor - Emitter Base (R2) (Ohms) | 47k |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 10mA, 5V |
| Vce Saturation (Max) @ Ib, Ic | 100mV @ 250μA, 5mA |
| Current - Collector Cutoff (Max) | 1μA |
| Frequency - Transition | 230MHz |
| Power - Max | 230mW |
| Mounting Type | Surface Mount |
| Package / Case | 6-XFDFN Exposed Pad |
| Supplier Device Package | DFN1010B-6 |
