NSB9435T1G
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | NSB9435T1G |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | TRANS PREBIAS PNP 0.72W SOT223 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| NSB9435T1G Price |  |
Technical Specifications of NSB9435T1G
| Datasheet |  NSB9435T1G datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - Bipolar (BJT) - Single, Pre-Biased |
| Manufacturer | ON Semiconductor |
| Series | - |
| Packaging | Tape & Reel (TR) |
| Transistor Type | PNP - Pre-Biased |
| Current - Collector (Ic) (Max) | 3A |
| Voltage - Collector Emitter Breakdown (Max) | 30V |
| Resistor - Base (R1) (Ohms) | 10k |
| Resistor - Emitter Base (R2) (Ohms) | - |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 125 @ 800mA, 1V |
| Vce Saturation (Max) @ Ib, Ic | 550mV @ 300mA, 3A |
| Current - Collector Cutoff (Max) | - |
| Frequency - Transition | 110MHz |
| Power - Max | 720mW |
| Mounting Type | Surface Mount |
| Package / Case | TO-261-4, TO-261AA |
| Supplier Device Package | SOT-223 |
