Technical Specifications of 2SD1802S-TL-E
| Datasheet |  2SD1802S-TL-E datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - Bipolar (BJT) - Single |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| Transistor Type | NPN |
|---|
| Current - Collector (Ic) (Max) | 3A |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 50V |
|---|
| Vce Saturation (Max) @ Ib, Ic | 500mV @ 100mA, 2A |
|---|
| Current - Collector Cutoff (Max) | 1μA (ICBO) |
|---|
| DC Current Gain (hFE) (Min) @ Ic, Vce | 140 @ 100mA, 2V |
|---|
| Power - Max | 1W |
|---|
| Frequency - Transition | 150MHz |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
|---|
| Supplier Device Package | 2-TP-FA |
|---|
We can supply ON Semiconductor part# 2SD1802S-TL-E. Use the request quote form to request 2SD1802S-TL-E pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 2SD1802S-TL-E. The price and lead time for 2SD1802S-TL-E depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 2SD1802S-TL-E. We look forward to doing business with you.
