Technical Specifications of FPN560
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - Bipolar (BJT) - Single |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Bulk |
|---|
| Transistor Type | NPN |
|---|
| Current - Collector (Ic) (Max) | 3A |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 60V |
|---|
| Vce Saturation (Max) @ Ib, Ic | 350mV @ 200mA, 2A |
|---|
| Current - Collector Cutoff (Max) | 100nA (ICBO) |
|---|
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 500mA, 2V |
|---|
| Power - Max | 1W |
|---|
| Frequency - Transition | 75MHz |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-226-3, TO-92-3 Long Body |
|---|
| Supplier Device Package | TO-226 |
|---|
We can supply Fairchild Semiconductor part# FPN560. Use the request quote form to request FPN560 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FPN560. The price and lead time for FPN560 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FPN560. We look forward to doing business with you.
