TPC8405(TE12L,Q,M)
.jpg)
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
| Manufacturer Part Number | TPC8405(TE12L,Q,M) |
|---|---|
| Manufacturer | Toshiba Semiconductor and Storage |
| Description | MOSFET N/P-CH 30V 6A/4.5A 8SOP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| TPC8405(TE12L,Q,M) Price |  |
Technical Specifications of TPC8405(TE12L,Q,M)
| Datasheet |  TPC8405(TE12L,Q,M) datasheet |
|---|---|
| Category | Discrete Semiconductor Products |
| Family | Transistors - FETs, MOSFETs - Arrays |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tape & Reel (TR) |
| FET Type | N and P-Channel |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 30V |
| Current - Continuous Drain (Id) @ 25°C | 6A, 4.5A |
| Rds On (Max) @ Id, Vgs | 26 mOhm @ 3A, 10V |
| Vgs(th) (Max) @ Id | 2V @ 1mA |
| Gate Charge (Qg) @ Vgs | 27nC @ 10V |
| Input Capacitance (Ciss) @ Vds | 1240pF @ 10V |
| Power - Max | 450mW |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.173", 4.40mm Width) |
| Supplier Device Package | 8-SOP (5.5x6.0) |
