Technical Specifications of 2SK3817-DL-E
| Datasheet |  2SK3817-DL-E datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Logic Level Gate, 4V Drive |
|---|
| Drain to Source Voltage (Vdss) | 60V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 60A (Ta) |
|---|
| Rds On (Max) @ Id, Vgs | 15 mOhm @ 30A, 10V |
|---|
| Vgs(th) (Max) @ Id | 2.6V @ 1mA |
|---|
| Gate Charge (Qg) @ Vgs | 67nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 3500pF @ 20V |
|---|
| Power - Max | 1.65W |
|---|
| Operating Temperature | 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | TO-252-3, DPak (2 Leads + Tab), SC-63 |
|---|
| Supplier Device Package | SMP-FD |
|---|
We can supply ON Semiconductor part# 2SK3817-DL-E. Use the request quote form to request 2SK3817-DL-E pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number 2SK3817-DL-E. The price and lead time for 2SK3817-DL-E depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# 2SK3817-DL-E. We look forward to doing business with you.
