Technical Specifications of APT14F100B
| Datasheet |  APT14F100B datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Microsemi Corporation |
|---|
| Series | POWER MOS 8? |
|---|
| Packaging | Tube |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 1000V (1kV) |
|---|
| Current - Continuous Drain (Id) @ 25°C | 14A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 980 mOhm @ 7A, 10V |
|---|
| Vgs(th) (Max) @ Id | 5V @ 1mA |
|---|
| Gate Charge (Qg) @ Vgs | 120nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 3965pF @ 25V |
|---|
| Power - Max | 500W |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-247-3 |
|---|
| Supplier Device Package | TO-247 [B] |
|---|
We can supply Microsemi Corporation part# APT14F100B. Use the request quote form to request APT14F100B pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number APT14F100B. The price and lead time for APT14F100B depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# APT14F100B. We look forward to doing business with you.
