Technical Specifications of CPH6337-TL-E
| Datasheet |  CPH6337-TL-E datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | ON Semiconductor |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | MOSFET P-Channel, Metal Oxide |
|---|
| FET Feature | Logic Level Gate, 1.8V Drive |
|---|
| Drain to Source Voltage (Vdss) | 12V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 3.5A (Ta) |
|---|
| Rds On (Max) @ Id, Vgs | 70 mOhm @ 1.5A, 4.5V |
|---|
| Vgs(th) (Max) @ Id | 1.4V @ 1mA |
|---|
| Gate Charge (Qg) @ Vgs | 5.6nC @ 4.5V |
|---|
| Input Capacitance (Ciss) @ Vds | 405pF @ 6V |
|---|
| Power - Max | 1.6W |
|---|
| Operating Temperature | 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | SOT-23-6 Thin, TSOT-23-6 |
|---|
| Supplier Device Package | 6-CPH |
|---|
We can supply ON Semiconductor part# CPH6337-TL-E. Use the request quote form to request CPH6337-TL-E pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CPH6337-TL-E. The price and lead time for CPH6337-TL-E depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CPH6337-TL-E. We look forward to doing business with you.
