Technical Specifications of FQP45N15V2
| Datasheet |  FQP45N15V2 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Fairchild Semiconductor |
|---|
| Series | QFET? |
|---|
| Packaging | Tube |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 150V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 45A (Tc) |
|---|
| Rds On (Max) @ Id, Vgs | 40 mOhm @ 22.5A, 10V |
|---|
| Vgs(th) (Max) @ Id | 4V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 94nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 3030pF @ 25V |
|---|
| Power - Max | 220W |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | TO-220-3 |
|---|
| Supplier Device Package | TO-220-3 |
|---|
We can supply Fairchild Semiconductor part# FQP45N15V2. Use the request quote form to request FQP45N15V2 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number FQP45N15V2. The price and lead time for FQP45N15V2 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# FQP45N15V2. We look forward to doing business with you.
