Technical Specifications of APT19F100J
| Datasheet |  APT19F100J datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Microsemi Corporation |
|---|
| Series | POWER MOS 8? |
|---|
| Packaging | Tube |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 1000V (1kV) |
|---|
| Current - Continuous Drain (Id) @ 25°C | 20A |
|---|
| Rds On (Max) @ Id, Vgs | 440 mOhm @ 16A, 10V |
|---|
| Vgs(th) (Max) @ Id | 5V @ 2.5mA |
|---|
| Gate Charge (Qg) @ Vgs | 260nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 8500pF @ 25V |
|---|
| Power - Max | 460W |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Chassis Mount |
|---|
| Package / Case | SOT-227-4, miniBLOC |
|---|
| Supplier Device Package | ISOTOP? |
|---|
We can supply Microsemi Corporation part# APT19F100J. Use the request quote form to request APT19F100J pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number APT19F100J. The price and lead time for APT19F100J depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# APT19F100J. We look forward to doing business with you.
