Technical Specifications of IRF7603TRPBF
| Datasheet |  IRF7603TRPBF datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - FETs, MOSFETs - Single |
|---|
| Manufacturer | Infineon Technologies |
|---|
| Series | HEXFET? |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| FET Type | MOSFET N-Channel, Metal Oxide |
|---|
| FET Feature | Standard |
|---|
| Drain to Source Voltage (Vdss) | 30V |
|---|
| Current - Continuous Drain (Id) @ 25°C | 5.6A (Ta) |
|---|
| Rds On (Max) @ Id, Vgs | 35 mOhm @ 3.7A, 10V |
|---|
| Vgs(th) (Max) @ Id | 1V @ 250μA |
|---|
| Gate Charge (Qg) @ Vgs | 27nC @ 10V |
|---|
| Input Capacitance (Ciss) @ Vds | 520pF @ 25V |
|---|
| Power - Max | 1.8W |
|---|
| Operating Temperature | -55°C ~ 150°C (TJ) |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) |
|---|
| Supplier Device Package | Micro8? |
|---|
We can supply Infineon Technologies part# IRF7603TRPBF. Use the request quote form to request IRF7603TRPBF pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IRF7603TRPBF. The price and lead time for IRF7603TRPBF depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IRF7603TRPBF. We look forward to doing business with you.
