Technical Specifications of GHIS060A120S-A2
| Datasheet |  GHIS060A120S-A2 datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Modules |
|---|
| Manufacturer | Global Power Technologies Group |
|---|
| Series | - |
|---|
| IGBT Type | Trench Field Stop |
|---|
| Configuration | Single |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 1200V |
|---|
| Current - Collector (Ic) (Max) | 120A |
|---|
| Power - Max | 680W |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 60A |
|---|
| Current - Collector Cutoff (Max) | 2mA |
|---|
| Input Capacitance (Cies) @ Vce | 8nF @ 30V |
|---|
| Input | Standard |
|---|
| NTC Thermistor | No |
|---|
| Mounting Type | Chassis Mount |
|---|
| Package / Case | SOT-227-4, miniBLOC |
|---|
| Supplier Device Package | SOT-227 |
|---|
We can supply Global Power Technologies Group part# GHIS060A120S-A2. Use the request quote form to request GHIS060A120S-A2 pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number GHIS060A120S-A2. The price and lead time for GHIS060A120S-A2 depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# GHIS060A120S-A2. We look forward to doing business with you.
