Technical Specifications of MG12100S-BN2MM
| Datasheet |  MG12100S-BN2MM datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Modules |
|---|
| Manufacturer | Littelfuse Inc. |
|---|
| Series | - |
|---|
| IGBT Type | Trench Field Stop |
|---|
| Configuration | Half Bridge |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 1200V |
|---|
| Current - Collector (Ic) (Max) | 140A |
|---|
| Power - Max | 450W |
|---|
| Vce(on) (Max) @ Vge, Ic | 1.7V @ 15V, 100A (Typ) |
|---|
| Current - Collector Cutoff (Max) | 1mA |
|---|
| Input Capacitance (Cies) @ Vce | 7.1nF @ 25V |
|---|
| Input | Standard |
|---|
| NTC Thermistor | No |
|---|
| Mounting Type | Chassis Mount |
|---|
| Package / Case | S-3 Module |
|---|
| Supplier Device Package | S3 |
|---|
We can supply Littelfuse Inc. part# MG12100S-BN2MM. Use the request quote form to request MG12100S-BN2MM pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number MG12100S-BN2MM. The price and lead time for MG12100S-BN2MM depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# MG12100S-BN2MM. We look forward to doing business with you.
