Technical Specifications of CM450DX-24S
| Datasheet |  CM450DX-24S datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Modules |
|---|
| Manufacturer | Powerex Inc. |
|---|
| Series | IGBTMOD? |
|---|
| Part Status | Active |
|---|
| IGBT Type | - |
|---|
| Configuration | Half Bridge |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 1200V |
|---|
| Current - Collector (Ic) (Max) | 450A |
|---|
| Power - Max | 3400W |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.15V @ 15V, 450A |
|---|
| Current - Collector Cutoff (Max) | 1mA |
|---|
| Input Capacitance (Cies) @ Vce | 45nF @ 10V |
|---|
| Input | Standard |
|---|
| NTC Thermistor | Yes |
|---|
| Mounting Type | Chassis Mount |
|---|
| Package / Case | Module |
|---|
| Supplier Device Package | Module |
|---|
We can supply Powerex Inc. part# CM450DX-24S. Use the request quote form to request CM450DX-24S pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number CM450DX-24S. The price and lead time for CM450DX-24S depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# CM450DX-24S. We look forward to doing business with you.
