Technical Specifications of GPA020A135MN-FD
| Datasheet |  GPA020A135MN-FD datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Global Power Technologies Group |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| IGBT Type | Trench Field Stop |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 1350V |
|---|
| Current - Collector (Ic) (Max) | 40A |
|---|
| Current - Collector Pulsed (Icm) | 60A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.3V @ 15V, 20A |
|---|
| Power - Max | 223W |
|---|
| Switching Energy | 2.5mJ (on), 760μJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 180nC |
|---|
| Td (on/off) @ 25°C | 25ns/175ns |
|---|
| Test Condition | 600V, 20A, 10 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | 425ns |
|---|
| Package / Case | TO-3 |
|---|
| Mounting Type | Through Hole |
|---|
| Supplier Device Package | TO-3P |
|---|
We can supply Global Power Technologies Group part# GPA020A135MN-FD. Use the request quote form to request GPA020A135MN-FD pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number GPA020A135MN-FD. The price and lead time for GPA020A135MN-FD depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# GPA020A135MN-FD. We look forward to doing business with you.
