Technical Specifications of IRG4BC40W-STRRP
| Datasheet |  IRG4BC40W-STRRP datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Infineon Technologies |
|---|
| Series | - |
|---|
| Packaging | Tape & Reel (TR) |
|---|
| IGBT Type | - |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 600V |
|---|
| Current - Collector (Ic) (Max) | 40A |
|---|
| Current - Collector Pulsed (Icm) | 160A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 20A |
|---|
| Power - Max | 160W |
|---|
| Switching Energy | 110μJ (on), 230μJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 98nC |
|---|
| Td (on/off) @ 25°C | 27ns/100ns |
|---|
| Test Condition | 480V, 20A, 10 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | - |
|---|
| Package / Case | TO-263-3, D2Pak (2 Leads + Tab), TO-263AB |
|---|
| Mounting Type | Surface Mount |
|---|
| Supplier Device Package | D2PAK |
|---|
We can supply Infineon Technologies part# IRG4BC40W-STRRP. Use the request quote form to request IRG4BC40W-STRRP pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number IRG4BC40W-STRRP. The price and lead time for IRG4BC40W-STRRP depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# IRG4BC40W-STRRP. We look forward to doing business with you.
