Technical Specifications of AUIRGP35B60PD-E
| Datasheet |  AUIRGP35B60PD-E datasheet |
|---|
| Category | Discrete Semiconductor Products |
|---|
| Family | Transistors - IGBTs - Single |
|---|
| Manufacturer | Infineon Technologies |
|---|
| Series | - |
|---|
| Packaging | Tube |
|---|
| IGBT Type | NPT |
|---|
| Voltage - Collector Emitter Breakdown (Max) | 600V |
|---|
| Current - Collector (Ic) (Max) | 60A |
|---|
| Current - Collector Pulsed (Icm) | 120A |
|---|
| Vce(on) (Max) @ Vge, Ic | 2.55V @ 15V, 35A |
|---|
| Power - Max | 308W |
|---|
| Switching Energy | 220μJ (on), 215μJ (off) |
|---|
| Input Type | Standard |
|---|
| Gate Charge | 55nC |
|---|
| Td (on/off) @ 25°C | 26ns/110ns |
|---|
| Test Condition | 390V, 22A, 3.3 Ohm, 15V |
|---|
| Reverse Recovery Time (trr) | 42ns |
|---|
| Package / Case | TO-247-3 |
|---|
| Mounting Type | Through Hole |
|---|
| Supplier Device Package | TO-247AD |
|---|
We can supply Infineon Technologies part# AUIRGP35B60PD-E. Use the request quote form to request AUIRGP35B60PD-E pirce and lead time. RANTLE EAST ELECTRONIC - ICRFQ.com is an independent stocking distributor of electronic components. With 5+ Million line items of available electronic components can ship in short lead-time, over 300 thousand part numbers of electronic components in stock for immediately delivery, which may include part number AUIRGP35B60PD-E. The price and lead time for AUIRGP35B60PD-E depending on the quantity required, availability and warehouse location. Contact us today and our sales representative will provide you price and delivery on Part# AUIRGP35B60PD-E. We look forward to doing business with you.
